Allproof 200mm Polymer Concrete channel is a moulded concrete strip drain that uses polymers to supplement cement as the binder material. This creates a highly durable drain with extremely low permeability making it the perfect solution for commercial applications.

The trench drain comes in 1m lengths with a 200mm clear opening. The channel has the option of either a stainless or cast-iron edge to match the grate choice. Grate options include stainless steel 316 wedge wire, SS 304 ladder, SS 304 LAS, cast iron or heelproof cast iron. Grates have been load class tested in accordance with AS3996 with results ranging from A – E, A caters for pedestrian foot traffic while E caters for heavy industrial areas. A selection of grates has also been slip resistance tested by an independent laboratory to AS4586, this provides assurances to product specifiers that Allproof’s Polymer Concrete trench drain reduces hazards in high foot traffic or fast moving areas.

Polymer Concrete trench drains physical and chemical characteristics along with its high performance provides an excellent solution for a wide variety of applications. Suitable commercial applications include loading docks, industrial yards, infrastructure (i.e. freeway / motorway shoulders), factory & production facilities (i.e. brewery’s / winery’s) as well as pedestrian areas and urban landscaping in light commercial projects (i.e. malls, pedestrian streets, car parks).

Allproof specification masterspec

Channels


Sumps


End Caps

End caps aren’t included with channels, please specify amount of end caps required by adding them in when selecting required channels for quote.

Revit Files


Install Drawings


Technical Documents


System Example

The system design accommodates runs of up to 43 meters, terminating at a sump. A mirror image can then be run in the opposite direction, resulting in maximum length of 76 meters between sumps. Overall system length is unlimited. This may be reduced dependent on required flow rates or other constraints. We suggest talking to a Hydraulics Consultant with your exact requirements.

PC Volume Capacity (L)
